Product Introduction
The HT series high temperature box furnace is an ultra-high temperature electric furnace using advanced materials and processes. It can reach a maximum temperature of 1800 degrees Celsius, with furnace volumes ranging from 4 liters to 52 liters. It can achieve high-temperature sintering under controlled atmosphere or high-temperature sintering under vacuum/controlled atmosphere. Heating elements and insulating lining materials can be specially designed and manufactured according to the user's specific experimental requirements.
Working Principle
Place workpieces inside the furnace chamber with reserved gaps between each piece. Spacing ensures unobstructed heat circulation across the entire working zone. Seal the furnace door after loading, then select and launch the matched heating program on the control panel.
Power input activates the chamber wall heating elements. Electric energy converts into heat energy. Thermal radiation acts as the primary heat transfer method, while internal natural convection assists full chamber heat coverage.
The built-in thermocouple captures real-time chamber temperature and transmits data to the PID controller. The controller compares sampled temperature with preset values and adjusts heating output dynamically. Complete heating cycles include temperature rise, constant holding and staged cooling. Operators set heating rate, peak temperature and holding duration according to workpiece material characteristics. Parameter consistency ensures repeatable thermal cycles for every production batch.
Features
01.
High-quality ceramic fiber insulation material for rapid heating and cooling.
01
02.
Double-layer furnace body ensures low outer wall temperature.
02
03.
Can operate in air, protective atmosphere, or vacuum environments with high temperature accuracy.
03
04.
Multiple temperature controllers are available.
04
05.
Standard furnace models and custom designs are available upon request.
05
Technical Specifications
Temperature Range:
1400℃, 1600℃, 1800℃, 1820℃, 2100℃
Effective Volume:
4 to 52 liters
Voltage:
400V/3PE, N/50Hz
Power:
3.5kW-16kW
Application
This high temperature box furnace supports fixed-value heating and staged thermal processing. It applies to metal thermal treatment, ceramic sintering, refractory material detection and laboratory sample research.
It handles annealing, tempering, aging and stress relief for various metal workpieces. Ceramic and refractory components complete high-temperature calcination and sintering inside the furnace chamber.
Compact chamber specifications adapt to daily material testing and sample preparation for research institutions. For industrial scenarios, we adjust chamber dimensions, heating element layout, loading fixtures and PID operating parameters to match workpiece specs and production throughput.
Product Detail
Electrical Control Cabinet
Electrical Control Cabinet
Heating Element
Heating Element
